Jazzy 614 HD Power Wheelchair 450 Lbs Capacity by Pride Mobility - Power Wheelchairs

Jazzy 614 HD Power Wheelchair 450 Lbs Capacity by Pride Mobility - Power Wheelchairs For Sale

The Pride Jazzy 614 HD Power Wheelchair features a 450 lbs. Weight Capacity and dual enhanced in-line motors for greater efficiency, torque, range and performance. The Jazzy 614 HD comes equipped with the Active-Trac ATX Suspension for enhanced performance over more varied terrain. The new standard depth-adjustable, fold-flat contemporary design high-back seat option offers maximum comfort. The 614 HD delivers outstanding performance and excellent maneuverability in a stylish package.

Dual enhanced in-line motors for greater efficiency, torque, range and performance
450 lbs. weight capacity
6 inches casters on front & rear for maximum stability
Active-Trac ATX Suspension for enhanced performance over more varied terrain
Easy rear access to batteries
Seating up to 24 inches width x 24 inches deep
Tool-less shroud removal
Easy serviceability
Depth adjustable foot platform
Model Jazzy 614 HD
Weight Capacity 450 LBS
Turning Radius 22.75"
Width 25.125"
Length 35.5" without front riggings
Maximum Speed* Up to 4.3 mph
Ground Clearance 2.625"
Front Wheels 6" solid casters
Drive Wheels 14"
Rear Wheels 6" solid casters
Drivetrain Two-motor, Mid-Wheel 6
Braking System Regenerative and electro-mechanical
Suspension Type Limited
High-Back Seating 24"W x 24"D (max. dimensions)
High-Back Seat-to-Floor Range 20.5" -23.5"
Synergy Seating 24"W x 24"D (max. dimensions)
Synergy Seat-to-Floor Range 17.75" - 19.75"
Standard Electronics 50A, Dynamic
Battery Size 12 volt, NF-22 (2 required)
Standard Battery Charger 5A, off board
Per-Charge Range* Up to 11 miles
Battery Weight 37 lbs. each
Base Weight 121.5 Lbs
Standard Seat Weight 51.5 lbs. (high-back)
Standard Seat Size 20" x 18"-20"
Medicare Code Coverage Group 2: Heavy Duty (K0824/K0825)
Color Options Red or Blue
